TwinWeaver

TwinWeaver is a longitudinal framework for LLM-based Patient Digital Twins. It serializes longitudinal patient histories into text, enabling unified event prediction as well as forecasting with large language models (LLMs). This framework transforms structured patient history—including demographics, labs, treatments, and genetics—into a single, human-readable text prompt, enabling LLMs to jointly forecast continuous biomarkers and predict discrete clinical events.

⚙️ Installation

Requirements

• Python 3.8 or higher
• Core dependencies: pandas, numpy, transformers, scikit-learn

Install from PyPi

To install the package:

pip install twinweaver

The following sections will explain the tutorials/examples and afterwards the quick start guide.

💡 Tutorials & Examples

The examples/ directory provides comprehensive tutorials to help you get up and running.

🔰 Core Tutorials

These notebooks cover the primary workflows for most users:

• 1. Basics Overview: examples/01_data_preparation_for_training.ipynb
  • Demonstrates how to convert raw patient data (events, constants, genetics) into the instruction-tuning text format used by TwinWeaver. This is the core step for preparing data for fine-tuning.
• 2. Inference: examples/02_inference_prompt_preparation.ipynb
  • Shows how to run inference using the TwinWeaver framework, including setting up the data manager and generating prompts.
• 3. End-to-End Workflow: examples/03_end_to_end_llm_finetuning.ipynb
  • A complete guide covering the entire pipeline from data ingestion to LLM fine-tuning.
  • NOTE: please install the packages required via the exact following line pip install twinweaver[fine-tuning-example] (torch CUDA version might need to be adapted to your system)

🚀 Advanced Usage & Integrations

For users needing custom behavior or specific integrations:

• Pretraining Data Conversion: examples/advanced/pretraining/prepare_pretraining_data.py
  • A script illustrating how to convert data for the pretraining phase, using template-based generation. Useful if you want to pretrain on your own large-scale unlabeled clinical data.
• Custom Splitting:
  • examples/advanced/custom_splitting/inference_individual_splitters.py: Example script for inference using individual splitters.
  • examples/advanced/custom_splitting/training_individual_splitters.ipynb: Notebook demonstrating training data generation with individual splitters.
• MEDS Data Import: examples/integrations/meds_data_import.ipynb
  • A tutorial on importing data in the Medical Event Data Standard (MEDS) format and converting it into TwinWeaver's internal format. Includes a synthetic data example.

🏗️ Framework Overview

TwinWeaver addresses the challenge of modeling sparse, multi-modal clinical time series by leveraging the generative capabilities of LLMs.

Core Components

1. Text Serialization: Transforms multi-modal inputs (diagnoses, laboratory measurements, genetic mutation panels) into a structured textual representation of longitudinal patient trajectories.
2. Unified Task Support:
   • Time-Series Forecasting: Forecasting frequently measured values such as blood biomarkers or vital signs.
   • Landmark Event Prediction: Predicting patient event status (e.g., survival, disease progression) at future time points using a landmarking framework.
3. Flexible Horizon: Supports sampling split times and prediction horizons to avoid overfitting to specific canonical time points.

🚀 Quick Start

Here's a minimal example to get you started with TwinWeaver:

import pandas as pd

from twinweaver import (
    DataManager,
    Config,
    DataSplitterForecasting,
    DataSplitterEvents,
    ConverterInstruction,
    DataSplitter,
)

# Load your patient data <----- assuming your data is in df_events, df_constant and df_constant_description
dm = DataManager(config=config)
dm.load_indication_data(df_events=df_events, df_constant=df_constant, df_constant_description=df_constant_description)
dm.process_indication_data()
dm.setup_unique_mapping_of_events()
dm.setup_dataset_splits()
dm.infer_var_types()

# This data splitter handles event prediction tasks
data_splitter_events = DataSplitterEvents(dm, config=config)
data_splitter_events.setup_variables()

# This data splitter handles forecasting tasks
data_splitter_forecasting = DataSplitterForecasting(
    data_manager=dm,
    config=config,
)

# We will also use the easier interface that combines both data splitters
data_splitter = DataSplitter(data_splitter_events, data_splitter_forecasting)

# Set up the converter instruction
converter = ConverterInstruction(
    nr_tokens_budget_total=8192,
    config=config,
    dm=dm,
    variable_stats=data_splitter_forecasting.variable_stats,  # Optional, needed for forecasting QA tasks
)

patient_data = dm.get_patient_data("patient_id_0")  # <--- Set your patient id here

forecasting_splits, events_splits, reference_dates = data_splitter.get_splits_from_patient_with_target(patient_data)

training_data = converter.forward_conversion(
    forecasting_splits=forecasting_splits[split_idx],
    event_splits=events_splits[split_idx],
    override_mode_to_select_forecasting="both",
)

# training_data now contains (Input, Target) pairs ready for LLM fine-tuning

For complete tutorials, see the Tutorials & Examples section above.

📊 Dataset Format

TwinWeaver expects three primary dataframes (or CSV files) as input. Example files can be found in examples/example_data/.

1. Longitudinal Events (events.csv)

Contains time-varying clinical data where each row represents a single event.

patientid	date	event_descriptive_name	event_category	event_name	event_value	meta_data	source
Unique identifier for the patient	Date of the event	Human-readable name used in the text output	(Optional) Category (e.g., lab, drug)	(Optional) Specific event identifier	Value associated with the event	(Optional) Additional metadata	(Optional) Source of the data - e.g. events or genetic

2. Patient Constants (constant.csv)

Contains static patient information (demographics, baseline characteristics). One row per patient.

patientid	e.g. birthyear	e.g. gender	...
Unique identifier for the patient	e.g. Patient's year of birth	e.g. Patient's gender	Any other static patient attributes

3. Constant Descriptions (constant_description.csv)

Maps columns in the constant table to human-readable descriptions for the text prompt.

variable	comment
Name of the column in the constant table	Description of the variable for the text prompt

📂 Dataset Types: Instruction vs. Pretraining

TwinWeaver supports two primary data formats, each serving a distinct stage in the model training pipeline:

1. Pretraining Data:

   • Purpose: Continued Pretraining (CPT) to adapt a general-purpose LLM to the clinical domain.
   • Format: A narrative-style serialization of the entire patient history. It does not contain specific questions or answers but rather presents the patient's chronological journey as a continuous text.
   • Goal: Enables the model to learn medical terminology, clinical relationships, and temporal dynamics in an unsupervised manner (next-token prediction).
   • Converter: twinweaver.pretrain.converter_manual_template.ConverterPretrain

2. Instruction Data:

   • Purpose: Supervised Fine-Tuning (SFT) to teach the model to perform specific clinical tasks.
   • Format: Structured into "Input" (Prompt) and "Target" (Completion) pairs.
     • Input: Patient history up to a specific time point + a list of specific questions (e.g., "Forecast the next 3 weeks of hemoglobin values").
     • Target: The ground truth answers to those questions.
   • Goal: Optimizes the model for specific downstream applications like forecasting and risk stratification.
   • Converter: twinweaver.instruction.converter_manual_instruction.ConverterInstruction

📝 Paper, Authors & Citation

The paper can be found on Arxiv.

The core authors are: Nikita Makarov, Maria Bordukova, Lena Voith von Voithenberg, Estrella Villanueva Pivel, Sabrina Mielke, Jonathan Wickes, Hanchen Wang, Derek Ma, Keunwoo Choi, Kyunghyun Cho, Stephen Ra, Raul Rodriguez-Esteban, Fabian Schmich, Michael Menden

If you use the package, please cite

TODO

The logo was generated with Nano Banana Pro.

🧞🧞 Genie Digital Twin (GDT)

Note: The specific implementation, training, and evaluation code for the GDT model mentioned in the TwinWeaver paper is located in MendenLab/GDT. This repository contains the core twinweaver framework.

GDT is a pan-cancer model instantiated using TwinWeaver, trained on over 93,000 patients across 20 cancer types.

Performance

GDT significantly reduces forecasting error, achieving a median Mean Absolute Scaled Error (MASE) of 0.87 compared to 0.97 for strong time-series baselines. Furthermore, it improves risk stratification, achieving an average C-index of 0.703 across survival, progression, and therapy switching tasks. GDT also demonstrates capabilities in zero-shot generalization to out-of-distribution clinical trials and supports an interpretable clinical reasoning extension.

Testing

To run the test suite:

pip install pytest pytest-cov
pytest tests/

📜 License

TwinWeaver is licensed under the Apache License 2.0. See LICENSE for details.

🤝 Contributing

We welcome contributions to TwinWeaver! Please follow these steps to contribute.

Development Setup

1. Clone the repository and install dependencies:

   git clone https://github.com/MendenLab/TwinWeaver
   cd twinweaver
   pip install -e .
   pip install -r examples/requirements.txt
   pip install pre-commit pytest pytest-cov
   pip install -r docs/requirements.txt


2. Install pre-commit hooks: We use pre-commit to ensure code formatting and quality checks run before you commit.

   pre-commit install


Running Tests

We use pytest for testing. To run the full test suite:

pytest tests/

Building Documentation

The documentation is built with mkdocs. To preview it locally:

mkdocs serve

Contribution Workflow

1. Create a New Branch: Always create a new branch for your feature or fix.

   git checkout -b feature/my-new-feature


2. Make Changes: Implement your feature or fix.
3. Run Tests & Linting: Ensure your code passes all tests and pre-commit hooks.
4. Submit a Merge Request:
   • Push your branch to the repository.
   • Open a Merge Request (Pull Request) against the main branch.
   • Describe your changes clearly in the MR description.
